NOVA Brackets NOVA แบร็กเก็ต

Metal Passive Self-Ligating Series ชุดแบร็คเก็ตโลหะแบบพาสซีฟ เซลฟ์ไลเกตติ้ง

➤ High Precision Torque and Rotation Control
➤ Friction-Optimized Slot Geometry
➤ Low-Profile Contour for Better Occlusal Clearance
➤ การควบคุมแรงบิดและการหมุนอย่างแม่นยำสูง
➤ ร่องจัดฟันที่ออกแบบมาเพื่อลดแรงเสียดทานอย่างเหมาะสม
➤ รูปทรงต่ำเพื่อความชัดเจนด้านการสบฟันที่ดีขึ้น

Key Features คุณสมบัติหลัก

  • Anatomical Dome Profile
  • Spherical Ball Hook Design
  • Laser-Marked Mesh Base
  • Precision Center Guide
  • รูปทรงโดมตามลักษณะทางกายวิภาค
  • ดีไซน์ตะขอทรงกลมแบบลูกบอล
  • ฐานตาข่ายเลเซอร์มาร์ค
  • แนวศูนย์กลางที่แม่นยำ

Prescription Options ตัวเลือก Prescription

📋 In orthodontics, brackets have small built-in angles to guide how teeth move. Two common designs are Roth and MBT. Each design controls two important angles called torque and tip. Torque controls how much the tooth leans forward or backward. Tip controls how much the tooth tilts side to side.

📋 ในการจัดฟัน แบร็กเก็ตแต่ละแบบมีมุมเล็ก ๆ ที่ช่วยควบคุมทิศทางการเคลื่อนของฟัน Roth และ MBT เป็นแบบที่ใช้กันบ่อย แต่ละแบบจะควบคุมมุมสำคัญสองอย่าง คือ torque และ tip Torque คือการควบคุมว่าฟันจะเอนไปข้างหน้าหรือข้างหลังแค่ไหน Tip คือการควบคุมว่าฟันจะเอียงไปทางซ้ายหรือขวาแค่ไหน

Maxillary UR5UR4UR3UR2UR1 UL1UL2UL3UL4UL5
Torque -7-7-2812 128-2-7-7
Tip 001095 591000
Mandibular LR5LR4LR3LR2LR1 LL1LL2LL3LL4LR5
Torque -22-17-11-1-1 -1-1-11-17-22
Tip 00700 00700
Maxillary UR5UR4UR3UR2UR1 UL1UL2UL3UL4UL5
Torque -7-7-2812 128-2-7-7
Tip 00784 48800
Mandibular LR5LR4LR3LR2LR1 LL1LL2LL3LL4LL5
Torque -17-12-6-6-6 -6-6-6-12-17
Tip 00300 00300
